Voltage Protector Over and Under High 40A 230V Relay Protection Over-current Automatic Protection

• Over-voltage protection
• Under-voltage protection
• Over-current protection
• Automatic recovery
• Voltage display (voltage measurement)
• Current display (current measurement)

Product Parameters:

1.Model number: CHVP
2.Power supply:220/230VAC 50/60Hz
3.Max.Loading power: 1~63A Adjustable(default:63A)
4.Over-voltage protection value range:240V~300V~OFF(default:270V)
5.Under-voltage protection value range:140V ~ 200V ~ OFF(default:170V)
6.Over-current adjustment range: 1-63A(default:63A)
7.Power-on delay time:1s~300s(default:30s)
8.Power consumption : <2W
9.Electric machinery life : 100,000 times
10.Installation:35mm DIN rail

Noted: When you first connect the product, you have to wait about 10 second (Power-on delay time:1s~300s(default:30s)), after the red light turn off, then the product will work.
